ND

The definition of a rubber isolation mounting is any configuration, round, square or rectangular with a known capacity and deflection. Acoustical solutions are in the 6 – 8 Hz frequency range. However, these very same low stress isolators can be stacked with steel shim plates between to achieve lower frequencies for vibration isolation. This grouping is typical of special purpose product. We add new designs in response to market requirements.
Size (Color Mark) Duro-meter Capacity Range (lbs) Max. Static Defl. (in)
A-Black 30 15-45 0.35
A-Green 40 30-75
A-Red 50 60-125
B-Black 30 50-100 0.40
B-Green 40 75-150
B-Red 50 110-235
B-White 60 180-380
B-Yellow 70 300-600
C-Green 40 140-260 0.50
C-Red 50 200-400
C-White 60 310-600
C-Yellow 70 520-1000
D-Yellow 70 1060-2100 0.50
DS-Yellow 70 2200-4300 0.50
